Steam jacketed cooking kettle | Sugar melting pot
Parameters
| Model | Electric heating 600L |
| Inclined mixing weight size(kg) | 300 |
| Size(mm) | 1350*1350*1050 |
| Inclined stirring power voltage(KW/V) | 2.2/380 |
You can now ask our project managers for technical details
The jacketed cooking kettle is a pot that can cook and fry food. It can be heated while continuously stirring automatically. The Jacketed kettle has the functions of heating, boiling, frying, etc. in the process of food processing.
Specifically, it can be used for the production of melted sugar, jam, pharmacy, milk, canned food, and braised meat. A stirring heating pot is a very good choice for heating food in large canteen-boiled food processing plants.
Cooking Mixer machine video display
Features of jacketed cooking kettle
- Large heating area. The welded construction of the inner and outer double spherical pots gives the steam jacketed kettle a large heating area.
- High thermal efficiency. Due to the sandwich design, the heat can be transferred to the ingredients more effectively and thus increase the heating efficiency.
- Easy to control the heating temperature: The jacketed kettle allows the user to adjust and control the heating temperature according to the demand.
- Heating speed and liquid material boiling time are short.
- High-quality material. The Jacketed cooking kettle is made of high-quality stainless steel.
Tilting type with stirring function parameters
| Heating type | Specification | Inclined mixing weight size(kg) | Size(mm) | Inclined stirring power voltage(KW/V) |
| Natural gas heating | 50L | 75 | 850*850*750 | 0.75/380/220 |
| 100L | 110 | 850*850*750 | 1.1/380/220 | |
| 200L | 140 | 950*950*800 | 1.1/380/220 | |
| 300L | 180 | 1050*1050*850 | 1.5/380 | |
| 400L | 220 | 1150*1150*900 | 1.5/380 | |
| 500L | 160 | 1250*1250*950 | 2.2/380 | |
| 600L | 300 | 1350*1350*1050 | 2.2/380 | |
| 2000L | / | / | 4/380 | |
| Electric heating | 50L | 75 | 850*850*750 | 0.75/380/220 |
| 100L | 110 | 850*850*750 | 1.1/380/220 | |
| 200L | 140 | 950*950*800 | 1.1/380/220 | |
| 300L | 180 | 1050*1050*850 | 1.5/380 | |
| 400L | 220 | 1150*1150*900 | 1.5/380 | |
| 500L | 260 | 1250*1250*950 | 2.2/380 | |
| 600L | 300 | 1350*1350*1050 | 2.2/380 | |
| 2000L | / | / | 4/380 |
Jacketed cooking kettle of function
The machine itself does not have a cover, but due to processing needs, we can customize the machine with a cover. But this needs to be explained to the salesperson before buying while customizing in advance and delivering on time. In addition, this machine can be selected according to the process of processed food.
The special design of the Taizy steam jacketed cooking kettle
The capacity of the Jacketed kettle is generally relatively large, usually 50L-2000L, and the capacity is very large. Then we will be more worried about a problem. We add so many ingredients at once, how to stir during the heating process? Our machine has a stirring function, which solves some of the stirring problems during the heating process. This is mainly to prevent the problem of sticking in the process of heating some viscous ingredients. For example, in the process of melting sugar, constant stirring is required.
How the material is poured out of the machine？
The machine with a small output can be tilted to pour out the heated material, and the machine with a large output is equipped with an outlet at the bottom. Such different designs not only consider convenience but also safety.
Why choose the Taizy steam-jacketed cooking kettle?
- The first is that it has a convenient mixing function. Machine mixing replaces manual work and frees hands.
- Second, many materials can be processed at one time, which saves time for batch processing.
- Third, it has a pouring function, which makes the process of boiling some soup m180+ore convenient.
- Fourth, the jacketed pot has a heat preservation function, and the double-layer design allows the pot to keep warm for some time.
- Finally, the jacketed pot has a temperature control function, and the temperature can be monitored from time to time during the heating process.
The heating method of the sugar melting pot
This jacketed mixing pot can be heated by electricity or gas. Gas heating includes natural gas, coal gas, biogas, and steam. The steam-heated machine has a pressure gauge. So, how to choose the heating method during the purchase of the machine? You can consider your own heating conditions and price. In some countries, electricity is more expensive, so you can choose natural gas heating. The steam in the production process can also be used for heating, which can save energy and maximize the use of energy.
Points to note when buying Sugar Melting Pot
Achievable temperature
The heating method of electric heating requires the addition of heat-conducting oil, and the maximum temperature can reach about 260°C, which is the highest temperature among these heating methods. Steam heating can reach 80-100℃, which is the lowest temperature among several heating methods. It is required when purchasing the machine
Volume size
In the process of heating and steaming, if a 100L pot is used, the amount of material that is impossible to put can reach 100L, so when we want to steam 100L things, we should choose a 200L model machine.
